The 6m–12m Aluminum Landing Pontoon Dock is engineered to deliver superior strength, longevity, and stability in marine environments. Constructed from marine-grade 6061-T6 aluminum alloy and welded using advanced MIG technology, this pontoon system ensures maximum corrosion resistance and structural integrity. Designed for residential, commercial, and industrial waterfront applications, the pontoon provides a safe, durable, and low-maintenance solution for boats, jet skis, and maritime operations.
| Item | Specification |
|---|---|
| Length Options | 6m – 12m |
| Frame Material | Marine Grade Aluminum Alloy 6061-T6 |
| Welding Process | MIG Welding |
| Decking Options | WPC Decking / Preserved Timber Decking |
| Float Material | High-Density Polyethylene (HDPE) |
| Float Filling | EPS Foam, Density 15 kg/m³ |
| Fender System | Rubber Impact-Absorbing Fenders |
| Connection System | Flexible Anti-Wave Pontoon Connectors |
| Application Type | For private docks, marinas, landing platforms, resorts, fishing bases |
6061-T6 Marine-Grade Aluminum Frame
Highly resistant to saltwater corrosion, delivering long-term durability even in harsh coastal environments.
Impact-Resistant Rubber Fenders
Absorb collision force between boats and the pontoon, extending service life and reducing maintenance.
High-Buoyancy HDPE Floats with EPS Core
Each float is filled with 15 kg/m³ EPS foam, ensuring unsinkable stability and excellent buoyancy performance.
Optional Decking Materials
Choose WPC (wood-plastic composite) for modern aesthetics and slip resistance, or preserved timber for natural texture.
This aluminum pontoon dock is ideal for:
Private boat docks & waterfront homes
Public marinas and yacht clubs
Commercial fishing harbors
Resort and leisure piers
Water sport facilities (kayaks, jet skis, sailboats)
Temporary landing platforms for construction or logistics
Q1: Is the pontoon suitable for saltwater environments?
Yes. The 6061-T6 marine-grade aluminum alloy provides excellent resistance to corrosion in both fresh and saltwater.
Q2: Can the pontoon be customized in size and layout?
Absolutely. Length, decking materials, and modular configurations can be tailored to project requirements.
Q3: What type of maintenance does the pontoon require?
Regular visual inspections are recommended, but the aluminum frame and HDPE floats require minimal long-term maintenance.
Q4: How durable are the rubber fenders?
The rubber fender system is designed for repeated impact absorption and offers long service life under continuous docking operations.
